155Mb/s SFP Transceiver Multi Mode duplex LC connector 2km 850nm/1310nm with DDM Function

Name: 155Mbs SFP Transceiver Multi Mode duplex LC connector 2km 850nm1310nm with DDM Function
Brand: NuFiber
Price: 1 USD

Buy cheap 155Mb/s SFP Transceiver Multi Mode duplex LC connector 2km 850nm/1310nm with DDM Function product

Brand Name : NuFiber

Model Number : FE-SX-MM1310

Place of Origin : China

MOQ : 1 piece

Payment Terms : L/C, T/T, Western Union,Credit Card

Supply Ability : 100,000 pcs per month

Delivery Time : Within 1-3 work days

Packaging Details : 10pcs/plastic bag, 200pcs/carton

Certification : CE FCC Rohs

Product Name : 155Mbps SFP Transceiver

Wavelength : 1310nm

Distance : 2KM

Connector : LC

DDM : Support

Fiber Type : Duplex LC Multi Mode

Power Supply : 3.3V

Working Temperature : 0-70℃

Manufacturer : Yes

Compatible : Cisco Huawei HP Juniper Etc...

Warranty : 1 year

Contact Now

155Mb/s SFP Transceiver Multi Mode duplex LC connector 2km 850nm/1310nm with DDM Function

Description:

NuFiber’s SFP-SX-MM1310 Transceiver is a high performance, cost effective module which have a duplex LC optics interface. Standard AC coupled CML for high speed signal and LVTTL control and monitor signals. The receiver section uses a PIN receiver and the transmitter uses a 1310nm VCSEL laser, up to 14dB link budge ensure this module SONET OC-3/SDH STM-1 2Km application.

Features:

►Up to 155Mb/s Data Links

►Hot-Pluggable

►Duplex LC connector

►Up to 550m on 50/125μm MMF

►850nm VCSEL laser transmitter

►Single +3.3V Power Supply

►Maximum Power <1W

►Industrial /Extended/ Commercial operating temperature range: -40°C to 85°C/-5°C to 85°C/-0°C to 70°C Version available

►RoHS compliant and Lead Free

Applications:

►SONET OC-3/SDH STM-1

►Fast Ethernet

►Other Optical Links

Optical Parameters(TOP = -40 to 85°C, VCC = 3.135 to 3.465 Volts)

Parameter	Symbol	Min.	Typical	Max.	Unit	Note
Transmitter Section:
Center Wavelength	λc	840	850	860	nm
Spectral Width	σ			0.85	nm
Optical Output Power	Pout	-10		-3	dBm	1
Optical Rise/Fall Time	tr / tf			500	ps	2
Extinction Ratio	ER	8.2			dB
Generated Jitter (peak to peak)	JTXp-p			0.07	UI	3
Generated Jitter (rms)	JTXrms			0.07	UI	3
Eye Mask for Optical Output	Compliant with G.957(class 1 laser safety)
Receiver Section:
Optical Input Wavelength	λc	770		870	nm
Receiver Overload	Pol	-8			dBm	4
RX Sensitivity	Sen			-24	dBm	4
RX_LOS Assert	LOS A	-40			dBm
RX_LOS De-assert	LOS D			-25	dBm
RX_LOS Hysteresis	LOS H	0.5			dB
General Specifications:
Data Rate	BR		155		Mb/s
Bit Error Rate	BER			10-12
Max. Supported Link Length on 50/125μm MMF@155Mb/s	LMAX		2		km
Total System Budget	LB	14			dB

Products Show:

155Mb/s SFP Transceiver Multi Mode duplex LC connector 2km 850nm/1310nm with DDM Function

Packing&Shipping

155Mb/s SFP Transceiver Multi Mode duplex LC connector 2km 850nm/1310nm with DDM Function

Factory Show
155Mb/s SFP Transceiver Multi Mode duplex LC connector 2km 850nm/1310nm with DDM Function

Ordering Informations:

Dual Fiber SFP Transmitter
Part Number	Product Description
155Mbp/s SFP Transmitter
FE-SX-MM850	155Mbps, 850nm MM 2km Dual LC, DDM 0°C~+70°C
FE-SX-MM1310	155Mbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C
FE-LX20-SM1310	155Mbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C
FE-LX40-SM1310	155Mbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C
FE-LX80-SM1550	155Mbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C
FE-LX120-SM1550	155Mbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C
1.25Gbps SFP Transmitter
GE-SX-MM850	1.25Gbps, 850nm MM 500m Dual LC, DDM 0°C~+70°C
GE-SX-MM1310	1.25gbps, 1310nm MM 2km Dual LC, DDM 0°C~+70°C
GE-LX20-SM1310	1.25Gbps, 1310nm SM 20km Dual LC, DDM 0°C~+70°C
GE-LX40-SM1310	1.25Gbps, 1310nm SM 40km Dual LC, DDM 0°C~+70°C
GE-LX60-SM1550	1.25Gbps, 1550nm SM 60km Dual LC, DDM 0°C~+70°C
GE-LX80-SM1550	1.25Gbps, 1550nm SM 80km Dual LC, DDM 0°C~+70°C
GE-LX120-SM1550	1.25Gbps, 1550nm SM 120km Dual LC, DDM 0°C~+70°C
10Gbps SFP Transmitter
SFP+-10GB-SR	10G SFP+ SR Multi mode dual fiber LC 850nm 300M
SFP+-10GB-LRM	10G SFP+ LRM Multi mode dual fiber LC 1310nm 220M
SFP+-10GB-LR	10G SFP+ LR Single mode dual fiber LC 1310nm 20km
SFP+-10GB-ER	10G SFP+ER Single mode dual fiber LC 1550nm 40km
SFP+-10GB-ZR	10G SFP+ZR Single mode dual fiber LC 1550nm 80km
SFP+10G40-CWDM	1470 ~1610nm CWDM SFP+ 40km
SFP+10G80-CWDM	1470~1570nm CWDM SFP+ 80km
SFP+10G80-CWDM	1590~1610nm CWDM SFP+ 80km
SFP+10G40-DWDM	DWDM SFP+ 40km
SFP+10G80-DWDM	DWDM SFP+ 80km
NF-CWDM-XFP40	1470 ~1610nm CWDM XFP 40km
NF-CWDM-XFP80	1470~1570nm CWDM XFP 80km
NF-CWDM-XFP80	1590~1610nm CWDM XFP 80km
NF-DWDM-XFP40	DWDM XFP 40km
NF-DWDM-XFP80	DWDM XFP 80km
NF-DWDM-XFP100	DWDM XFP100km

Welcome to send us inquiry for this products .
